2. Specication
Model AH1-070B/140B AH1-280B AH1-560B/730B
Connected AHU capacity
3 <x ≤7KW(070B)
7 x ≤14KW(140B)
14
＜
x ≤28KW(5-10HP)
8 < x ≤56KW(560B)
56 < x ≤73KW(730B)
Power supply 220-240V/50/60Hz 220-240V/50/60Hz 220-240V/50/60Hz
Dimention(W/D/H) 420/260/165 420/260/165 420/260/165
Shipping dimensions 520*340*225 520*340*225 520*340*225
Material Galvanized steel Galvanized steel Galvanized steel
Color Grey Grey Grey
Weight/kg 5.5 5.5 6.5
Shipping Weight/kg 8.5 8.5 10
Liquid pipe (mm) 9.52(Main) /6.35 9.52(Main) /6.35 12.7
（
Main
）
/15.88
Pipe connection method
Flare connection and
welding
Flare connection and
welding
Flare connection and
welding
Branch box-Indoor Max Single
pipe length/m
5 5 5
Branch box- indoor max drop/
m
5 5 5
