INSTALLATION INSTRUCTIONS
2. Install the dryer with stacking kit on the top of the front load washing
machine (Fig.3). Drill two holes on both sides of washer with 2.9mm
diameter drill. Detailed drill postion as shown on the stacking kit. Make
sure the included screws are used. Fix the stacking kit on the top
cover of washing machine, as shown on Fig.4.
12
Dryer
Washer
Stacking kit
Fig.3
Fig.4
Change the venting mode
There are three venting options:
Front venting
The exhaust grill has a range of positions, which allows you to select the optimum
exhaust air angle. Simply hold the grill and rotate it until you reach the desired position.
Note: If the dryer is mounted on the wall you must use the front venting option.
