46
10.4 IR Board
715G3963R01000004S
IRRV
56G 627911
33G8032 5F HR
81G 14 24 EL
C201
0.1uF 10V
BLUE
VOUT
1
GND
2
VCC
3
U201
KSM-603TM2M
3V3_STB
R201 15K OHM 1/10W
RED
1
2
3
4
5
6 7
CN201
CONN
1
23
4
RED
BLUE
LED201
LED
0402
LED_B
LED_R
1
GNDGNDPIN
