Haier HNSE05BB User Manual

1. Remove the top hinge cover.
2. Using Phillips Head Screwdriver, loosen and remove the screws holding the
top hinge in place.
3. Remove top hinge and carefully lift off the door.
4. Remove the screw hole plugs from the opposite side and insert the plugs in
the screw hole openings of the just removed screws.
5. Remove any loose items in the refrigerator and carefully turn refrigerator on
its back, remove both leveling legs and place in a secure area.
6. Loosen the screws holding the lower hinge bracket to the refrigerator and
remove screws and bracket.
7. Remove (2) screws from the other side and insert in the previously removed
screw holes.
8. Remove door pin by turning counter clockwise and reinsert to the underside
of the bracket and tighten.
9. Align bracket and insert (2) remaining screws into the holes provided .
10. Align hole in the door with the door pin and washer and gently push down
until firm.
11. Align upper hinge bracket with screw holes insert screws and partially secure,
check that door and cabinet are properly aligned and then secure tightly.
12. Replace hinge cap.
6
Reversing The Door Hinge
English

Haier HNSE05BB Specifications

General

Product color	Black
Reversible doors	Yes
Appliance placement	Freestanding
No Frost system	No
Power requirements	115 V, 60 Hz
Total gross capacity	130.25 L
Annual energy consumption	342 kWh

Weight and Dimensions

Depth	565 mm
Width	516 mm
Height	814.4 mm
Weight	30001 g
