Haier HP200M2 User Manual

5
3. Technical parameters
Model HP200M2 HP250M2 HP250CM2
Tank volume 200L 250L 245L
Rated voltage/ frequency 230V/50Hz 230V/50Hz 230V/50Hz
Tank rated pressure 0.85MPa 0.85MPa 0.85MPa
Corrosion protection Magnesium rod Magnesium rod Magnesium rod
Water proof grade IPX4 IPX4 IPX4
Type of extraction Ambient / Exterior Ambient / Exterior Ambient / Exterior
COP@7
℃
/ EN16147 2.5
2.5
2.5
COP@15
℃
/ EN16147 2.9 2.9 2.9
Tapping cycle L L L
Electric heater power 2150W 2150W 2150W
Average
input - heat pump only 665W 665W 665W
Maximum input- heat pump only 850W 850W 850W
Maximum total power input of the
appliance
3000W 3000W 3000W
Standby power input/ Pes 33W 33W 33W
Max volume of usable hot water at 40
℃
setting at 55 ℃
230L 300L 275L
Heating up time (7
℃ ) 6.5h 8.5h 8.2h
Heating up time (15
℃ ) 5.0h 6.8h 6.7h
Default temperature setting 55
℃ 55 ℃ 55 ℃
Temperature setting range- with heater 35 ℃ -75 ℃ 35 ℃ -75 ℃ 35 ℃ -75 ℃
Pressure drop in air circuit 25Pa 25Pa 25Pa
Max working pressure of refrigerant 0.8/2
.8MPa 0.8/2.8MPa 0.8/2.8MPa
Refrigerant type / weight R134a/0.9kg R134a/0.9kg R134a/0.9kg
Noise pressure level (2m) 40dB 40dB 40dB
Ambient temperature for use of product -5~35
℃ -5~35 ℃ -5~35 ℃
Operating temperature of heat pump -5~35 ℃ -5~35 ℃ -5~35 ℃
Water inlet and outlet connection G3/4"F G3/4"F G3/4"F
Safety valve connection G3/4"F G3/4"F G3/4"F
Drain & Water intlet connection G3/4"F G3/4"F G3/4"F
Product Dimensions
600*629*1692mm 600*629*1987 mm 600*629*1987 mm
Packing dimension without pallet 736*695*1810 mm 736*695*2120 mm 736*695*2120 mm
Packing dimension with pallet 736*695*1940 mm 736*695*2250 mm 736*695*2250 mm
Net/Gross weight 104/118kg 117/131kg 136/150kg
* The COP and noise level data was tested in Haier lab
Tank
Performances
Dimension and connections
