5.4 Value of Thermistor
5.4.1 intdoor Unit
Room sensor
R25 =23KΩ±3.5%℃
B25 /50 =4200K±3%℃℃
Temp.(℃)
Max.(KΩ) Normal(KΩ) Min.(KΩ)
Tolerance(℃)
-30 568.8372 501.0746 440.8435 -1.97 1.75
-29 530.9600 468.6491 413.1441 -1.95 1.74
-28 495.8488 438.5314 387.3645 -1.93 1.72
-27 463.2850 410.5433 363.3602 -1.91 1.71
-26 433.0683 384.5212 340.9980 -1.90 1.70
-25 405.0156 360.3153 320.1558 -1.88 1.69
-24 378.9588 337.7879 300.7211 -1.86 1.67
-23 354.7440 316.8126 282.5905 -1.84 1.66
-22 332.2300 297.2732 265.6686 -1.82 1.64
-21 311.2873 279.0627 249.8676 -1.80 1.63
-20 291.7969 262.0831 235.1067 -1.78 1.62
-19 273.6494 246.2437 221.3111 -1.76 1.60
-18 256.7445 231.4612 208.4122 -1.74 1.59
-17 240.9897 217.6590 196.3462 -1.72 1.57
-16 226.3000 204.7662 185.0545 -1.70 1.56
-15 212.5973 192.7176 174.4829 -1.68 1.54
-14 199.8093 181.4531 164.5813 -1.66 1.53
-13 187.8698 170.9169 155.3033 -1.64 1.51
-12 176.7176 161.0578 146.6059 -1.62 1.49
-11 166.2961 151.8284 138.4495 -1.60 1.48
-10 156.5532 143.1847 130.7973 -1.58 1.46
-9 147.4409 135.0863 123.6153 -1.56 1.44
-8 138.9148 127.4956 116.8717 -1.53 1.43
-7 130.9337 120.3778 110.5374 -1.51 1.41
-6 123.4597 113.7009 104.5852 -1.49 1.39
-5 116.4577 107.4349 98.9897 -1.47 1.38
-4 109.8953 101.5523 93.7278 -1.45 1.36
-3 103.7422 96.0274 88.7774 -1.43 1.34
-2 97.9708 90.8365 84.1185 -1.40 1.32
-1 92.5551 85.9574 79.7322 -1.38 1.30
0 87.4712 81.3697 75.6011 -1.36 1.29
1 82.6970 77.0544 71.7088 -1.34 1.27
2 78.2118 72.9937 68.0402 -1.31 1.25
3 73.9966 69.1712 64.5813 -1.29 1.23
4 70.0335 65.5716 61.3188 -1.27 1.21
5 66.3062 62.1807 58.2405 -1.24 1.19
6 62.7992 58.9853 55.3351 -1.22 1.17
7 59.4984 55.9729 52.5917 -1.20 1.15
8 56.3905 53.1320 50.0006 -1.17 1.13
9 53.4631 50.4521 47.5523 -1.15 1.11
33
'RPHVWLF$LU&RQGLWLRQHU
+68182HVA103/R2(DB))XQFWLRQV DQG &RQWURO
