3-3. Power Board
3-3-1 Function Description:
Supply power for Main board, Panel.
&RQQHFWRUGH¿QLWLRQ
- 11 -
CN3
Pin number Signal name
9 GND
GND
GND
GND
GND
10 GND
11 GND
12 +12V
13 +12V
POWER ON/OFF
+5VSTB
+5V
+5V
514C2632M04
514C3205M02
CN2
Pin number Signal name
9 GND
GND
GND
GND
GND
10 GND
11 GND
12 +12V
13 +12V
POWER ON/OFF
+5VSTB
+5V
+5V
514C2632M04 514C3205M02
ADJ
ON/BK
