-5-

Front panel

30 30

1: Remote control sensor.

2: Indicator LED: LED OFF POWER ON.

RED STANDBY.

3: Key board

KEYBOARD

VOL+

INPUT

VOL-

1. VOL+/ VOL- :

Adjust sound level.

In Menu mode, press " VOL+" or "VOL-" to adjust the

item that you selected.

2. CH / CH :

In TV mode, press "CH+" or "CH-" to change the channel

up and down.

In MENU mode, press "CH+" or "CH-" to select items.

In standby mode, press "CH+" or “CH- " to turn on the

T V.

3. INPUT :

Display the input source menu.

4. MENU :

Display main MENU.

5. :

Press this button to turn the unit ON from STANDBY

mode.

Press it again to turn the set back to STANDBY.

INSTALLATION

REAR AV Connections(SIDE)

All the terminals are (from up to down):

USB, ANT/CABLE, EARPHONE, HDMI 2.
