4
1
12
13
Before rst use: Unpack Food Processor and remove protective
covers from the Blades and Disc. Handle Blades and Disc
carefully; they are very sharp. Wash all parts except Base in hot,
soapy water. Rinse; then dry.
9
4
3
10
14
7
Parts and Features
To order parts, visit:
hamiltonbeach.com/parts
6
1 Large Food Pusher
2 FEED CHUTE MAX FILL Line
3 Lid
4 Lid Latches
5 MAX FILL Line (small bowl)
6 Small Bowl with Tabs
7 Large Bowl
8 Feed Chute
9 Small Food Pusher
10 Pour Spout
11 MAX Fill Line (large bowl)
12 Nonremovable Motor Shaft
13 Base
14 Control Panel
2
5
8
11
