User’s Manual
23
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 19.0"
LCD Panel
Pixel pitch 0.2835mm(H) x 0.2835mm(V)
H-Frequency 30KHz – 80KHz
Video
V-Frequency 55 – 75Hz
Display Colors 16.2M Colors
Max. Resolution 1440 x 900 @75Hz
Plug & Play
VESA DDC2B
TM
ON Mode
≤42W
Power Saving Mode
≤1W
EPA ENERGY STAR
®
OFF Mode
≤1W
Audio output Rated Power 1.0 W rms (Per channel)
Input Terminal
D-Sub
DVI-D (Dual-Input Model)
Maximum Screen Size
Hor. : 428mm
Ver. : 278mm
Power Source 100~240VAC,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 0° to 50°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 80%
Dimensions
443 (W) x 379.7(H) x 200(D) mm
17.5 ”(W)×15.0 ”(H)×8.0 ”(D)
Weight (NW) 444.5kg (9.9 lb)
***The above specification is subject to actual product specification and is subject to
change without prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can
refer to www.hannsg.com
FAQ section.
