Hardi NAVIGATOR 4000 Supplement To Instruction Book

8 - Technical specifications
8.2
Weight
Navigator 3000 (800 Gal.):
Navigator 3500 (1000 Gal.):
Navigator 4000 (1200 Gal.):
Wheel and axle dimensions
Boom width Axle load* Drawbar load* Total weight* Axle load** Drawbar load** Total weight**
60’ 6978 309 7286 12780 2222 15000
66’ 7004 315 7319 12800 2233 15040
80’ 6878 617 7496 12810 2403 15210
88’ 6949624 7573 12930 2407 15290
90’ 6971 635 7606 129502421 15320
100
’ 7077 661 7738 13010 244715450
*Weights with empty tank
**Weights with full tank
All measurements are in pounds (lbs)
Boom width Axle load* Drawbar load* Total weight* Axle load** Drawbar load** Total weight
**
60’ 6991 329 7320 14330 2495 16820
66’ 7017 336 735314360 2505 16860
80’ 6865 665 7530 13810 3220 17030
88’ 6963 644 7607 14580 2525 17110
90’ 6985 655 764014610 2535 17140
100’ 7091 681 7772 14680 2594 17270
*Weights with empty tank
**Weights with full tank
All measurements are
in pounds (lbs)
Boom width Axle load* Drawbar load* Total weight* Axle load** Drawbar load** Total weight**
60’ 7011 331 734114700 2538 17260
66’ 7037 337 7374 14730 2546 17300
80’ 6911 639 755114830 2579 17470
88’ 6982 646 7628 14960 2635 1755
0
90’ 7004 657 7661 14980 264617580
100’ 7110 683 7793 15050 2668 17710
*Weights with empty tank
**Weights with full tank
All measurements are in pounds (lbs)
Axle type Track width
Fixed 60”
Fixed 120”
Combo60” - 120”
Wheel
Fixed axle
clearance*
Modified axle
clearance*
Combo axle
clearance*
12.4 x 4229” 25” 28”
320/90 R4632” 28” 31”
*under axle
