REAR-PANEL CONNECTIONS 9
REAR-PANEL CONNECTIONSREAR-PANEL CONNECTIONS
Tape Inputs:
Connect these jacks to the PLAY/OUT
jacks of an audio recorder.
AM Antenna Terminals: Connect the AM loop
antenna supplied with the receiver to these terminals.
If an external AM antenna is used, make connections
to the AM and GND terminals, in accordance with
the instructions supplied with the antenna.
FM Antenna Jack: Connect the supplied indoor
(or an optional external) FM antenna to this terminal.
NOTE ON VIDEO CONNECTIONS: When connecting
a source device such as a VCR, DVD player, cable or
satellite set-top box or video game to the AVR, use
either a composite or S-Video connection for each input,
but not both.
38
37
36
AVR 235 OM 8/30/04 9:18 AM Page 9
