46
Table A2 – Source Setting Defaults
Cable/Sat DVD Media Server Radio TV Game AUX The Bridge
Surround Modes (Auto Select) Logic 7 Movie Logic 7 Movie Logic 7 Music Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Music Logic 7 Music
Video Input HDMI 2 HDMI 1 HDMI 4 N/A
Component 1
HDMI 3
Composite Front The Bridge III
Audio Input HDMI 2 HDMI 1 HDMI 4 N/A Optical 1 HDMI 3 Coaxial Front
The Bridge III
Resolution to Display
*
480i
*
480i 480i 480i 480i 480i 480i 480i
Audio Auto Polling Off Off Off N/A Off Off Off N/A
Zone 2 Audio Analog 1 Analog 2 Analog 5 Radio Analog 3 Analog 4 Analog Front
The Bridge III
Dolby Volume Medium Low Medium Medium Medium Medium Low Medium
*
Video output resolution may vary for HDMI connections.
Appendix – Default settings, worksheets, remote product codes
Table A1 – Recommended Source Component Connections
Device Type AVR 2600 Source Digital Audio Connection Analog Audio Connection Video Connections
Cable TV, satellite TV, HDTV Cable/SAT HDMI 2 Analog 1 HDMI 2
or other device that delivers
television programs
DVD Audio/Video, SACD, DVD HDMI 1 Analog 2 HDMI 1
Blu-ray Disc, HD-DVD player
Media Server, including Media Server HDMI 4 Analog 5 HDMI 4
Harman Kardon DMC 1000
TV TV Optical 1 Analog 3 Component 1
*
Video game console Game HDMI 3 Analog 4 HDMI 3
Any audio or video device, AUX Coax Front Analog Front Composite Front (not used for
e.g., CD player, camcorder, audio-only devices)
cassette deck
Recorder Any Coaxial 2 Input and Analog 4 Inputs and Outputs Composite Video 2 Input
Coaxial Output and Output
iPod or iPhone The Bridge III None The Bridge III The Bridge III for photo- and
video-capable iPod and iPhone
models
*
Make this connection only when using the TV source for a non-display device. Do not connect your television’s or video display’s video output to the AVR at any time.
APPENDIX
AVR 2600 OM.qxd 4/29/09 12:10 PM Page 46
