Harman Kardon AVR 3500 Specification

Specifications
•Audio Section – Continuous Average Power (FTC):
(Stereo Mode): 55 watts per channel into 8 ohms @
20Hz – 20kHz, <0.07% THD, both channels driven;
(Five-Channel Surround Mode): 45 watts per channel
into 8 ohms @ 20Hz – 20kHz, <0.07% THD, all
channels driven; High Instantaneous Current
Capability (HCC): ±28 amps
•Tuner – Usable Sensitivity: IHF 1.3µV/13.2dBf; THD at
1kHz with 100% Modulation: (Mono) 0.2%, (Stereo)
0.3%; FM Adjacent Channel Selectivity: ±400kHz,
70dB; Ultimate (Maximum) S/N Ratio (measured at
1mV RF Input Level): (Mono) 70dB, (Stereo) 68dB
•General – Dimensions (H x W x D): 165mm x 440mm
x 435mm; Weight: 14kg
NOTE: Depth measurement includes knobs, buttons
and terminal connections; height measurement
includes feet and chassis.
Features
•45W x 5 Into 8 Ohms, 20Hz – 20kHz at <0.07%
THD, With All Channels Driven Simultaneously
•High-Current (±28 Amps), Ultrawide-Bandwidth
(10Hz – 100kHz) Amplifier Design Effortlessly Powers
the Most Dynamic Digital Sources
•EzSet Remote Provides Manual and Automatic
Calibration of Audio Output Levels, and Is
Programmable to Control up to Six Devices
•Dolby Digital and DTS Decoding Using Advanced Twin
24-Bit Core Crystal
®
Chip Digital Engine
•192kHz/24-Bit DACs
•Dolby Pro Logic II (Movies, Music and Emulation
Modes) Surround Sound is Compatible With Older
Stereo Material But Delivers Detail That Approaches
Digital 5.1 Formats
•Harman-Exclusive Logic 7 Cinema and Music
Surround Sound Processing for Superior Soundstage
Imaging and Playback of Both Surround-Encoded and
Stereo Recordings
•Two Modes of VMAx Virtual Surround Sound Deliver
the Home Theater Experience With Only Two
Speakers
•5-Channel Stereo, Hall and Theater Surround Sound
Modes
•MP3 Decoding Through Coaxial or Optical Digital
(S/P-DIF) Inputs Enables Playback of Hours of Music
From a Compatible Computer
•FM Stereo/FM/AM Tuner With 30 Presets and Direct-
Access Tuning
•Preamp Outputs for All Channels Allow the Use of
External Amplifiers
•Subwoofer Output for Direct Connection to Powered
Subwoofer
•Five A/V Inputs with S-Video and Four Audio Inputs
•6-Channel Direct Inputs for Use With External
Surround Decoders
•Six Digital Inputs (Two Optical and Two Coaxial on
Rear Panel, and One Optical and One Coaxial on
Front Panel)
•Two Digital Outputs (One Optical and One Coaxial)
•Front-Panel A/V Input With S-Video
•On-Screen Display
•Programmable Power-Up Volume
•Rotary Bass, Treble and Balance Controls
All features and specifications are subject to change
without notice.
*Trademarks of Dolby Laboratories. DTS is a registered
trademark of Digital Theater Systems, Inc. EzSet is a
trademark of Harman International Industries, Inc.
(patent no. 5,386,478). Crystal is a registered
trademark of Cirrus Logic Corp. Logic 7 is a registered
trademark of Lexicon, Inc., a Harman International
Company. VMAx is a registered trademark of Harman
International Industries, Inc., and is an implementation
of Cooper Bauck Transaural Stereo under patent
license. Harman Kardon is a registered trademark,
and Power for the Digital Revolution is a trademark,
of Harman Kardon, Inc.
DTS
Dolby Pro Logic II
Logic 7
VMAx
front-panel inputs
MP3 decoding
EzSet
ultrawide bandwidth
Dolby Digital
high-current
capability
192kHz/24-bit DACs

Harman Kardon AVR 3500 Specifications

Power

continuous average power (stereo mode)	55 watts per channel into 8 ohms
continuous average power (five-channel surround mode)	45 watts per channel into 8 ohms
high instantaneous current capability (HCC)	±28 amps

Tuner Specifications

usable sensitivity	IHF 1.3µV/13.2dBf
THD at 1kHz with 100% modulation (mono)	0.2%
THD at 1kHz with 100% modulation (stereo)	0.3%

Weight and Dimensions

dimensions (H x W x D)	165mm x 440mm x 435mm
weight	14kg
