Harman Kardon AVR 355 Service Manual

R×5VT
5
•
TO-92
PIN CONFIGURATION
•
SOT-89
•
SOT-23-5
PIN DESCRIPTION
•
TO-92
•
SOT-89
•
SOT-23-5
Pin No. Symbol
1 OUT
2 VDD
3 GND
4 NC
5 NC
Pin No. Symbol
1 OUT
2 VDD
3 GND
Pin No. Symbol
1 OUT
2 VDD
3 GND
1 2
3
(mark side)
1 2
3
(mark side)
1 2
3
(mark side)
5
4
harman/kardon
AVR 355/230 Service Manual
Page 89 of 125

Harman Kardon AVR 355 Specifications

General

Brand	Harman Kardon
Model	AVR 355
Category	Receiver
Language	English
