REAR - PANEL CONNECTIONS
Analog 1-5 Inputs
6/8 Channel Inputs
Video
1, 2 & 3
Inputs
Remote
IR Input
Zone 2
IR Input
SIRIUS
Tuner
The Bridge III
Remote
IR Output
HDMI 1-4
Inputs
HDMI
Monitor
Output
Video
Monitor
Output
Center
Speaker
Outputs
Switched AC
Accessory
Outlet
Main
Power
Switch
Component
1 & 2
Inputs
Surround
Back/
Zone 2
Speaker
Outputs
Front
Speaker
Outputs
Zone 2 Audio Outputs
AM Antenna
FM Antenna
Carrier IR
Output
Analog 2 & 4
Audo Outputs
Surround
Speaker
Outputs
A-BUS Port
Component Video
Monitor Output
AC Power Input
Video 2
Output
A-BUS
IR Output
Subwoofer
Output
C
oaxial
Digital
Audio
Output
Coaxial 1 & 2 Digital Audio
Inputs
Optical 1-3
Digital
Audio
Inputs
Preamp
Outputs
Fan Vents
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at www.harmankardon.com.
