Model Name: CITATION SURROUND
• Signal-to-noise ratio: >80dB
• Output power: 2x50W RMS
• Power Supply: 100-240V ~ 50/60Hz
• Power consumption in sleep mode: <2.0Watts
• 5G WISA transmitter power: <14dBm
• 5G WISA modulation: OFDM, BPSK, QPSK, 16QAM
• 5G WISA transmitter frequency range: 5.15 - 5.35GHz,
5.470 - 5.725GHz, 5.725 - 5.825GHz
• Dimension (W x H x D): 105 x 273 x 86mm (4” x 10.7” x 3.3”)
• Weight: 1.29kg (2.84 lb)
• Packaging Dimension (W x H x D): 235 x 383 x 150mm
(10” x 15” x 6”)
• Packaging Weight (Gross): 3.57kg (7.87 lb)
Note: This product is designed to be instantly on and ready
to receive signal from WiSA Tx Unit at a moment's notice,
wireless connection must remain active at all times to ensure
proper operation.
The product is in compliance with the European Union
energy legislation. The product will enter into sleep mode
(networked standby) after 20 minutes without operation,
after which it can be re-activated via wireless.
SPECIFICATION
5
