FUNCTION SWITCHES
Sidechain: Routes external sidechain input signal to the detector.
OverEasy
®
: Activates the OverEasy‚ compression function.
Auto: Activates automatic program-dependent attack and release times,
disabling the manual attack and release controls.
PeakStopPlus
®
:Activates the Intelligent Predictive Limiting® (Stage 2) section of the limiter.
Bypass: Activates the direct input-to-output hard-wire relay bypass. Relay
automatically hard-wire bypasses unit at power-down and provides a
power-on delay of 1.5 seconds.
Input: Monitors the input signal and shows its level on the VU meter. Peak
indicator lights for signals >+21dBu.
Output: Monitors the output signal and shows its level on the VU meter. Peak
indicator lights for signals >+21dBu.
GR: Monitors the compressor and PeakStopPlus limiter and displays the
total amount of gain reduction on the lower scale of the VU meter.
Pin 1 Lift (Rear Panel) Lifts pin 1 of the input XLR and 1/4” sleeve from chassis ground.
INDICATORS
Compressor Threshold Meter: 3 LED indicators at Below, OverEasy®, and Above.
Sidechain: 1 LED to indicate when external sidechain is selected.
Auto: 1 LED to indicate when Auto mode is selected.
PeakStopPlus
®
:1 Bi-Color LED. When PeakStopPlus® function is not engaged, the
LED will be off when signal is below Stop Level threshold, and will
light redwhen signal is above threshold. When PeakStopPlus®
functionis engaged, the LED will be green when signal is below Stop
Level threshold, and will turn red when signal is above threshold.
Bypass: 1 LED to indicate when 162SL is bypassed.
Input/Output/GR 3 LEDs to indicate which meter mode is selected. Green for input
level, yellow for output level, and red for gain reduction.
POWER SUPPLY
Operating Voltage: Factory selected: 100-120V, 120V, or 220-240VAC 50/60Hz.
Power Consumption: 28 Watts maximum.
Fuse: 100V-120V: T 400mA 250V; 5mm X 20mm
220V-240V: T 200mA 250V; 5mm X 20mm
Mains Connection: IEC 320 Receptacle
PHYSICAL
Dimensions: 3.5”H X 19”W X 10”D
Weight: 11.2 lbs (5.1 kg)
Shipping Weight: 13.0 lbs (5.9 kg)
Note: 0dBu = 0.775V RMS
All Trademarks and Registered Trademarks are the property of their respective owners.
28
