DJdi DIRECT BOX
Converting the Output of Unbalanced Devices
The DJdi can be quite useful on stage, or in a studio when connecting unbalanced devices, particularly keyboards. The low
output signal levels of many keyboards can benefit greatly by connecting their unbalanced outputs to the DJdi. By doing so,
the signal can then be sent cleanly for long distances and utilize the low noise common mode rejection provided by the DJdi’s
balanced low-level output.
Specifications
CIRCUIT:
Type: Passive
INPUTS:
Number of Connectors: 2
Connection: 1/4” TS (Tip Hot, Sleeve Ground)
Type: Unbalanced, RF Filtered
Input Impedance: 50 kOhm
OUTPUTS:
Number of Connectors: 2
Connection: Male XLR, Balanced, Pin 2 hot
Output Impedance: 600 Ohms
Noise Level: -104dBu (22Hz -22kHz, Input Shorted)
THD+N (10Hz-22kHz): 0.23% typical @ +4dBu @ 1kHz
Insertion Loss: 21dB typical
PHYSICAL:
11.98cm (W) x 13.99cm (L) x 3.98cm (H)
4.72” (W) x 5.51” (L) x 1.57” (H)
dbx is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be
made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or
shown.
