9
DRAFT
DRAFT
BACK PANEL
A. Power Button
Press the Power Button to engage power.
B. Crossover Frequency
Select the frequency you wish by pressing the Crossover Frequency
Button (B). Choose crossover frequency EQ from one type to another type
(cycling) by repeatedly pressing the Crossover Frequency Button (B).
C. Polarity Button
Toggle polarity between ON and OFF
D. Master Volume
Controls the master volume of the unit. By turning the knob counter-
clockwise you will be lowering the overall volume of the speaker. By turning
the control clockwise you will be increasing the overall volume of the
speaker.
E. XLR-1/4” Combo Inputs
These balanced inputs accepts a standard XLR (female) connector and
also a 1/4” TRS phone plug. These only accept line line level, not mic level
directly.
F. XLR Male Loop Thru
This XLR (male) output connector provides a method of sending audio
out to an external source. If signal is present on both inputs, this sub will
route directly through the signal from channel 1 to thru for channel 1 and
signal from channel 2 to the thru for channel 2.
G. Power Receptacle
Connect the supplied power cord to the power receptacle
on the rear of the speaker. Connect the power cord to an available power outlet.
