Harman Martin MAC Aura XIP User Manual

DMX protocol 33
Extended Mode
MAC Aura XIP firmware version 1.0.0.
See “Pixel mapping” on page 9 for details of Beam pixel numbering.
Channels 1 - 36: as in Basic Mode
Beam Pixel color (Pixel Color Control of 7 x Beam LEDs, Global Beam RGB channels are added to this using
HTP)
37
0 - 255
Pixel 1 Red
0 - 100%
Fade 0
38
0 - 255
Pixel 1 Green
0 - 100%
Fade 0
39
0 - 255
Pixel 1 Blue
0 - 100%
Fade 0
40
0 - 255
Pixel 2 Red
0 - 100%
Fade 0
41
0 - 255
Pixel 2 Green
0 - 100%
Fade 0
42
0 - 255
Pixel 2 Blue
0 - 100%
Fade 0
43
0 - 255
Pixel 3 Red
0 - 100%
Fade 0
44
0 - 255
Pixel 3 Green
0 - 100%
Fade 0
45
0 - 255
Pixel 3 Blue
0 - 100%
Fade 0
46
0 - 255
Pixel 4 Red
0 - 100%
Fade 0
47
0 - 255
Pixel 4 Green
0 - 100%
Fade 0
48
0 - 255
Pixel 4 Blue
0 - 100%
Fade 0
49
0 - 255
Pixel 5 Red
0 - 100%
Fade 0
50
0 - 255
Pixel 5 Green
0 - 100%
Fade 0
51
0 - 255
Pixel 5 Blue
0 - 100%
Fade 0
52
0 - 255
Pixel 6 Red
0 - 100%
Fade 0
53
0 - 255
Pixel 6 Green
0 - 100%
Fade 0
54
0 - 255
Pixel 6 Blue
0 - 100%
Fade 0
55
0 - 255
Pixel 7 Red
0 - 100%
Fade 0
56
0 - 255
Pixel 7 Green
0 - 100%
Fade 0
57
0 - 255
Pixel 7 Blue
0 - 100%
Fade 0
