SUB B10 Service Manual
11 OF 32
SPECIFICATIONS
Frequency Response
+/–0.5dB in the pass-band
Low Frequency
–3dB at 35Hz
Extension (Anechoic)
–6dB at 32Hz
–10dB at 29Hz
Maximum Amplifier
Output
20Hz – 150Hz with no more than
0.1% THD, 800W, 1500 peak
Low-Pass Crossover
Frequencies
50Hz – 150Hz, 24dB/octave,
continuously variable
Power Requirements
100 – 120V, 50/60Hz
220 – 240V, 50/60Hz 7AMP
Power Consumption
0.5W (standby)
Height
16.45" (41.8cm), including feet
Width
14.83" (37.7cm)
Depth
15.45" (39.2cm) with grille
Weight
47 lb (21.3kg)
Features, specifications and appearance are subject to
change without notice.
