28
XXV Pellet Stove
The Harman Direct Vent Wall Passthrough makes
installing your Harman Pellet Stove with outside air a
lot easier. It is made to t walls from 4 1/2" up to 10 1/8"
thick with a square opening of 6" to 6 1/2".
The Top Flue option attaches to the exhaust on the rear of the stove, and extends it to the top with a
six inch stub.
This gives the appearance of a wood stove and also allows venting with existing single wall, connector.
A 12 inch piece of 4" pellet vent is included to act as an insulator only. Note: The top ue adaptor is not
approved for use with pellet vent pipe. It is only tested for use with chimney connector (6- inch pipe) into
an existing "class A" chimney.
Passthrough
hole for 3" PL
vent pipe
Outdoor Half
Indoor Half
Adjustable from 4 1/2" to 10 5/8" wall thickness
Side View
