Hayward AQL-CHEM4-ACID User Manual

AQLTACID Rev A
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS 6
SPARE PARTS:
Tank Cap CLX-LFCAP
Check Valve CAX-3511
PART NUMBER DESCRIPTION NO. REQ’D
ACX03590120 PUMP ASSEMBL
Y
WITH 13’ TUBING AND 31.68 GPD SPARE FEED TUBE 1
CAX-3504 PVC BLUE SUCTION TUBE(SOFT) (13 FT ROLL)
CAX-3505 PVC BLUE SUC
T
ION TUBE(SOFT) (300 F
T
ROLL)
CAX-3508 3X7 SANTOPRENE FEED TUBE 6.14GPD
CAX-3509 ROLLER ASSEMBL
Y
for 31.68 GPD
CAX-3511 NEXT GEN. PP 1/4" INJECTION CHECK VALVE
CAX-3512 3X7 SANTOPRENE FEED TUBE-31.68GPD (Standard) 1
CAX-3513 CLEAR FRONT HAYWARD COVER LENS FOR THE PUMP
CAX-3514 SECONDARY CATCH BASIN
GLX-LFCAP BLUE TANK CAP 100mm 1
GLX-LFTUBE PICK UP TUBE ASSEMBLY WITH FITTING, SEAL RING and INLET FILTER 1
GLX-LFCOVER COVER, Rain Shield 1
GLX-LFTAN
K
15 GALLON TANK WITH PUMP MOUNTING BRACKE
T
F
eed Tube
CLX-3512
or
CLX-3508
Pick Up Tube
Assy
GLX-LFTUBE
PUMP – ACX03590120
