Hayward SharkVAC User Manual

1
1-Handle
2-Nut
3-Tube
4-Screw
5-Base
3
5
12
Caddy Cart Instructions – See Diagram
1. Caddy Cart will come partially assembled in the carton less the handle & tube. (1 & 3)
2. Insert the screw into the tube at the base of the caddy cart & secure with bolt (4)
3. Insert the handle into the top of the tube & insert the screw securing it with the bolt
(1&2)

Hayward SharkVAC Specifications

Power

current consumption	0.78 amps
primary voltage	110-120 volt AC (220-240 volts for 240 volt model)
secondary voltage	24V DC

Motor Specifications

speed	2, 700 rpm
voltage	24V DC, 22V DC, 5V DC
current	2.62 amps, 0.63 amps

Filter

filter type	removable, re-usable, pleated element cartridge
filter porosity	100 micron
filter area	1, 150 sq. inches

Weight and Dimensions

weight without cable	21.5 lbs
cable length	50 ft
shipping weight	21.5 lbs (19.1 kg)
