Hayward SharkVAC User Manual

14
To Remove the filter cartridges:
x Unsnap and lift up both filter door
latches.
x Pull out the filter cartridges. Using a
garden hose with a spray nozzle, wash
the filter elements to remove debris.
Hold the filter elements as shown to
allow the debris to fall out.
x Wash the entire filter bucket assembly.
(Previously Shown)
x Place the filter cartridges back into the
filter bucket assembly with the center
frame reinforcements facing inward.
To Remove the lter cartridges:

Hayward SharkVAC Specifications

Power

current consumption	0.78 amps
primary voltage	110-120 volt AC (220-240 volts for 240 volt model)
secondary voltage	24V DC

Motor Specifications

speed	2, 700 rpm
voltage	24V DC, 22V DC, 5V DC
current	2.62 amps, 0.63 amps

Filter

filter type	removable, re-usable, pleated element cartridge
filter porosity	100 micron
filter area	1, 150 sq. inches

Weight and Dimensions

weight without cable	21.5 lbs
cable length	50 ft
shipping weight	21.5 lbs (19.1 kg)
