HELI CPC 25 User Manual

2.Clutch and Clutch Pedal
Table 2
2.1 General Description
The clutch consists primarily of pressure plate, friction piece and clutch yoke.
The pressure plate is bolted to the engine flywheel. There is an inspection hole
attached to the clutch cover. The clutch pedal pushes the clutch yoke by push rod in
order to release the friction piece from flywheel which normally mesh together.
2.2 Replacement of Friction Piece
(1) Press the clutch pedal and place three spacers between the pressure plate case
and release lever to cause the friction piece apart.
(2) Turn counter clockwise the slide lead screw in the upper of the transmission
to let the driving shaft go into the transmission (See Fig.3-1).
(3) Remove six mounting bolts on the pressure plate case to cause the flywheel
apart and remove the old friction piece right away.
(4) When a new friction piece is installed, notice the hub (See part 5 in Fig.2-1)
with the longer spline boss being toward the transmission.
(5) Turn the slide lead screw clockwise and pull out the driving shaft step by step
and let its spline match with the hub spline.
CPC20、25、30、35、38
Single plate, dry
275
175
8.0
352
about 10
Foot operated
Truck Model
Parameters
Type
Dimensions
of Friction
Piece
mm
Outer dia.
Inner dia.
Thickness when pressed
2
Friction Surface Area cm
Weight kg
Operation Mode
-14-
