Thermal Printer C-56
Part No. 2 684 019 Rev. No. 4310715 eli page 2 of 17
Release
Release 1.0
C.Bernhart Mar 03
th
, 2005
Approved Hengstler E.Link
Approved
Changes
Date Rev Additional Content
09 Nov 2004 1.0 First Release
03 Jun 2005 1.1 RS 232 extension
26 Jul 2005 1.2 Update technical data, troubleshooting
17 Jul 2006 1.3 Update USB cable spec; add safety hint
21 Jan 2008 1.4 Update spare parts; add EMC hints; adding sensor options
15 May 2009 1.5 Revise EMC specs.
5 Aug 2009 1.6 Add 12 volt specs, chute sensor, hardware PPE sensor. Add reference to short
chute shroud.
17 Oct 2011 1.7 Add limitation on reversing paper. Added German paper specification. Removed
reference to German operating manual with wrong P/N.
3 Apr 2013 1.8 Clarify serial pinout; add wiring diagram for serial connection cable; correct height-
width-depth abbreviations; modified warning definition;
30 Jul 2015 1.9 Addition of chapter 2.3 and power supply pinout; various minor corrections
© 2005 - 2015 by HENGSTLER
This document is protected by copyright by HENGSTLER GmbH.
This document may not be changed, altered, duplicated or reproduced in any manner, or provided
or transmitted to any third persons or organizations, without the prior written approval of
HENGSTLER.
We reserve the right to make technical changes, modifications or improvements without prior
notice.
Hengstler and the Hengstler logo are registered trademarks of Hengstler GmbH. Other brand and
product names used herein are trademarks or registered trademarks of their respective companies.
HENGSTLER GmbH
Uhlandstr. 49
78554 Aldingen / Germany
Tel. +49 (0) 7424-89 0
Fax +49 (0) 7424-89 500
eMail: info@hengstler.com
www.hengstler.com
