Need help?Do you have a question about the Hikmicro Thunder TH35PC and is the answer not in the manual?
General| Resolution | 384 × 288 |
|---|---|
| Pixel Pitch | 12 μm |
| Lens | 35 mm |
| Digital Zoom | 1x, 2x, 4x, 8x |
| Detection Range | 1800 m |
| Aperture | F1.0 |
| Image Mode | White Hot, Black Hot, Red Hot, Fusion |
| Hot Track | Yes |
| Protection Level | IP67 |
| Thermal Sensitivity | <35 mK |
| Frame Rate | 50 Hz |
| Focus | Manual |
| IP Rating | IP67 |
| NETD | <35 mK |
| Display | OLED, 1024x768 |
| Battery Type | Rechargeable Li-ion |
| Power Supply | DC 5V/2A |
| Dimensions | 187 x 62 x 59 mm |
| Operating Temperature | -20°C to 55°C |
| Sensor Type | VOx Uncooled Focal Plane Arrays |
| Spectral Range | 8 μm to 14 μm |
| Storage Temperature | -40°C to 70°C |
