HIKVISION DS-2CD753F-E User Manual

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
3
DS-2CD753F-E(I)(Z)
Key Features
 Up to 2 megapixel (1600 × 1200) resolution, and real time video encoding at HD 720P
 Standard video compression with high compression ratio
 Progressive scan CMOS, capture motion video without incised margin
 Support e-PTZ
 Support Motorized VF lens
 Support dual stream, and the sub-stream for mobile surveillance
 Up to 32 GB SD/SDHC card for on-board storage
 Two-way audio
 PoE (Power over Ethernet)
 Auto-iris, electronic shutter for different surveillance environments
 Support analog video output for adjustment and installation
 3-axis (pan/tilt/rotation) positioning allows adjustment for optimum camera rotation and position
 Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up to IK10
 Other functions: heartbeat, PTZ control, alarm, reset button, mirror, etc.
Specification
Model
Parameter
DS-2CD753F-E(I)(Z)
2 Megapixel CMOS Vandal-proof Network Dome Camera
Camera
Image Sensor
1/3” Progressive Scan CMOS
Min.
Illumination
0.5 Lux @ (F1.2, AGC ON), 0.1 Lux @ (F1.2, AGC ON, sensitivity × 5)
-I: 0.5 Lux @ (F1.2, AGC ON), 0.1 Lux @ (F1.2, AGC ON, sensitivity × 5)
0 Lux with IR
Shutter Speed
1/25 s to 1/100,000 s
Lens
2.7-9mm @ F1.2,Angle of view: 101°-30.4°
