HIKVISION DS-2CE11D8T-PIRL User Manual

3.2 LANGUAGE
Supports English, and Chinese.
3.3 WHITE LIGHT
The embedded white light source can be worked as the
visible alarm, or the lighting.
In the WHITE MODE, you can set the mode as ALARM,
LIGHTING, or OFF.
3.3.1 ALARM
In the ALARM mode, you can select the TRIGGER
MODE as DVR, or CAMERA.
DVR
Select the TRIGGER MODE as DVR. In this way, the
alarm signal is sent from the DVR, and the camera
works as the alarm detector in the process. Besides, the
alarm type only supported by the DVR can also triggers
the visible alarm in the camera.
CAMERA
Select the TRIGGER MODE as CAMERA, the embedded
PIR module sends the alarm signal to the visible alarm
in the camera, when PIR module detected the alarm
source.
3.3.2 LIGHTING
Select the LIGHTING mode, the embedded white light
source turns on in poor light conditions.
Note:
 Type I camera do not have LIGHTING mode.
 Under the LIGHTING mode, the image is colored all
the time, and there’s no DAY NIGHT settings in the
menu.
3.3.3 OFF
Select OFF to give up this function.
3.4 MAIN MENU
3.4.1 AE (AUTO EXPOSURE)
Auto Exposure describes the brightness-related
parameters, which can be adjusted by BRIGHTNESS,
EXPOSURE MODE, AGC, and SENSE UP.
EXPOSURE
BRIGHTNESS
EXPOSURE MODE
AGC
SENSE UP
RETURN
5
GLOBAL
MIDDLE
0
Figure 3-3 AE
BRIGHTNESS
Brightness refers to the brightness of the image.
You can set the brightness value from 1 to 10 to darken
or brighten the image. The higher the value is, the
brighter the image is.
EXPOSURE MODE
You can set the EXPOSURE MODE as GLOBAL, BLC, and
WDR.
 GLOBAL
GLOBAL refers to the normal exposure mode which
adjusts lighting distribution, variations, and
non-standard processing.

HIKVISION DS-2CE11D8T-PIRL Specifications

General

Full HD	Yes
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Image quality adjustment	Brightness, Sharpness
Analog signal format system	NTSC, PAL
Fixed focal length	2.8 mm
Number of cameras	1
Pan range	0 - 360 °
White balance	ATW, Manual
Tilt angle range	0 - 180 °
Angle of rotation	360 °
Camera shutter speed	1/50000 - 1/25 s
Minimum illumination	0 lx
Type	CCTV security camera
Languages support	CHI (TR), ENG
Number of languages	2
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Sensor type	CMOS
Lens mount interface	M12
Interface	BNC
Built-in HDD	No
LED type	IR
Night vision distance	20 m
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Housing material	Metal
International Protection (IP) code	IP67
Operating temperature (T-T)	-40 - 60 °C
DC output voltage	12
Power source type	DC
Power consumption (max)	4.5 W
Power over Ethernet (PoE)	-

Weight and Dimensions

Depth	68 mm
Width	70 mm
Height	179.8 mm
Weight	345 g
