HIKVISION DS-2TD4166-50-V2 Quick Start Guide

Thermal Network Speed Dome Quick Start Guide
2
2 Appearance Description
There are three kinds of thermal network speed domes: Type I speed dome, Type II
speed dome, and Type III speed dome. The appearance description of three cameras are
shown below.
2.1 Speed dome Appearance
Refer to the following figures for thermal speed domes overview.
Type I Speed Dome Type II Speed Dome Type III Speed Dome
Figure 2-1 Thermal Speed dome Overview
2.2 Cable Descriptions
The cable interfaces of speed dome are shown in Figure 2-2. The cables of RS-485,
power supply, alarm inputs, alarm outputs, etc. are distinguished by different colors.
Please refer to the labels attached on the cables for identification.

HIKVISION DS-2TD4166-50-V2 Specifications

General

Brand	HIKVISION
Model	DS-2TD4166-50-V2
Category	Security Camera
Language	English
