HIKVISION DS-7604NI-SE/P User Manual

User Manual of Network Video Recorder
139
3) In the Device Management interface, click to register the device.
Figure 9. 11 Register the Device
4) Input Device Serial No., Device Domain (Device Name) and HTTP Port. And click OK to
add the device.
 Access the Device via Web Browser or Client Software
After having successfully registered the device on the HiDDNS server, you can access your device
via web browser or Client Software with the Device Domain Name (Device Name).
 OPTION 1: Access the Device via Web Browser
Open a web browser, and enter http://www.hik-online.com/alias in the address bar. Alias refers to
the Device Domain Name on the device or the Device Name on the HiDDNS server.
Example: http://www.hik-online.com/nvr
If you mapped the HTTP port on your router and changed it to port No. except 80, you have to
enter http://www.hik-online.com/alias:HTTP port in the address bar to access the device. You can
refer to Chapter 9.2.11 for the mapped HTTP port No.
 OPTION 2: Access the devices via iVMS-4200
For iVMS-4200, in the Add Device window, select and then edit the device
information.
Nickname: Edit a name for the device as you want.
Server Address: www.hik-online.com
Device Domain Name: It refers to the Device Domain Name on the device or the Device Name
on the HiDDNS server you created.
User Name: Enter the user name of the device.
Password: Enter the password of the device.

HIKVISION DS-7604NI-SE/P Specifications

General

Product color	Black
Channels quantity	4 channels
Playback resolutions supported	5MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Audio input	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
HDD capacity	1000 GB
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	445 x 290 x 45 mm
