User Manual of Network Video Recorder
97
Figure 6. 18 Smart Playback Interface
Table 6. 5 Detailed Explanation of Smart Playback
Button
Operation
Button
Operation
Button
Operation
Smart search
Stop
/
Pause play /
Play
Process bar
/
Scaling
up/down the
time line
Playback type
3. Select a camera in the camera list and select a date in the calendar.
4. Edit the smart search areas and rules.
1) Click the button to enter the search area editing interface; the smart search area is set as full screen
by default.
Figure 6. 19 Draw Area of Smart Search
2) Set the rules and areas.

Table of Contents

Other manuals for HIKVISION DS-7604NI-SE/P

Preview: Quick Operation Guide
Quick Operation Guide59 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7604NI-SE/P and is the answer not in the manual?

HIKVISION DS-7604NI-SE/P Specifications

General IconGeneral
Product colorBlack
Channels quantity4 channels
Playback resolutions supported5MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Audio input1
USB 2.0 ports quantity2
Ethernet LAN (RJ-45) ports5
Ethernet interface typeFast Ethernet, Gigabit Ethernet
HDD capacity1000 GB
HDD interfaceSerial ATA
Maximum HDD capacity4000 GB
Power consumption (typical)15 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Weight2000 g
Dimensions (WxDxH)445 x 290 x 45 mm
