Digital Video Recorder User Manual
143
Figure 6-22 Interface of External File Playback
6.1.9 Playing Back Pictures
The playback by picture is supported by the DS-7300/8100/9000HUHI-F/N series DVR only.
Purpose
The captured pictures stored in the HDDs of the device can be searched and viewed.
Step 2 Enter Playback interface.
Menu>Playback
Step 3 Select Picture from the drop-down list in the upper-left corner of the page to enter the
Picture Playback interface.
Step 4 Check checkbox to select the channel(s) and specify the start time and end time for
search.
Step 5 Click Search to enter Search Result interface.
Up to 4000 pictures can be displayed each time.
Step 6 Choose a picture you want to view and click button.
You can click Back to return to the search interface.
