Specification of DS-9600NI-XT
Model
DS-9616NI-XT
DS-9632NI-XT
DS-9664NI-XT
Video/Audio
input
IP video input
16-ch
32-ch
64-ch
Two-way audio
1-ch, BNC (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
80Mbps
160Mbps
160Mbps
Outgoing bandwidth
240Mbps
160Mbps
160Mbps
Remote Connection
128
Video/Audio
output
Recording resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF
/QCIF
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω)
Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
HDMI output
1-ch, resolution:
1920 × 1080P /60Hz, 1920×1080P /50Hz, 1600 × 1200/60Hz, 1280
× 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280
× 720 /60Hz, 1024 × 768 /60Hz
Audio output
2-ch, BNC (Linear, 600Ω)
Decoding
Live view / Playback
resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF
/QCIF
Capability
16-ch@720P, 8-ch@1080P
Hard disk
SATA
16 SATA interfaces for 16 HDDs
eSATA
2 eSATA interfaces
Capacity
Up to 4TB capacity for each HDD
Disk array
Array type
RAID0, RAID1, RAID5, RAID10
Number of array
16
External
interface
Network interface
2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces
Serial interface
RS-232; RS-485; Keyboard;
USB interface
3 × USB 2.0
Alarm in
16
Alarm out
4
Others
Power supply
100 ~ 240 VAC, 6.3 A, 50 ~ 60 Hz
Consumption
(without hard disks)
≤ 45 W
Working
temperature
-10 ºC ~ +55 ºC (14ºF ~ 131ºF)
Working humidity
10 % ~ 90 %
Chassis
19-inch rack-mounted 3U chassis
Dimensions
(W × D × H)
445 × 496 ×146 mm (17.5" ×19.5"× 5.7")
Weight
(without hard disks)
≤ 12.5 Kg (27.56 lb)
