Technical Specifications
Model
DS-9016HF
Video
Compression
H.264
Preview
Resolution
4CIF
Playback
Resolution
720P/4CIF/DCIF/2CIF/CIF/QCIF
Analog Video
Input
16-ch, BNC(1.0Vp-p, 75Ω), PAL/NTSC adaptive
Digital Video
Input
16-ch or 8-ch high definition (HIKVISION network
protocol)
Max Composited
Video Input
24-ch(Analog + Digital)
Video Output
2-ch, BNC(1.0Vp-p, 75Ω)
Frame Rate
PAL: 1/16~25FPS, NTSC: 1/16~30FPS
Compression
Output Bit Rate
16Kbps~4Mbps self-defined, max 8Mbps
Audio
Compression
OggVorbis
Audio Input
16-ch, BNC(2Vp-p, 1kΩ)
Audio Output
2-ch, standard 3.5mm audio interface
BNC (Linear Electrical Level, 600Ω)
Audio Output Bit
Rate
16kbps
Preset Number
256
Patrol Number
4
Pattern Number
1
Voice Talk
2-ch, BNC(2Vp-p, 1kΩ)
Communication
Interface
1 RJ45 10M/100M/1000M Adaptive Ethernet Interface
Serial Interface
1 RS-232(for parameter configuration, device
maintenance, transparent channel), 1 RS-485(for PTZ
control), 1 RS-485 keyboard(for special keyboard
control)
SATA Interface
8 build-in SATA interfaces, each HD support up to 2TB
capacity
USB Interface
2 USB2.0 interfaces, can support USB flash memory, USB
HDD USB mouse, USB DVD-R/W and CD-R/W
VGA Interface
1 VGA interface, support resolution: 1024*768*60Hz,
1280*1024*60Hz
