Specifications
Model
DS-9100HFI-S
Video/Audio
input
Video
compression
H.264
Video input
4/8/16-ch, BNC(1.0Vp-p, 75Ω)
PAL/NTSC adaptive
Audio
compression
OggVorbis
Audio input
4/8/16-ch, BNC(2Vp-p, 1kΩ)
Voice talk
input
2-ch, BNC(2Vp-p, 1kΩ)
Video/Audio
output
Preview
resolution
PAL: 704×576 NTSC: 704×480
VGA output
1, resolution:
1024×768/60Hz
1024×768/70Hz
1280×1024/60Hz
Playback
resolution
4CIF/DCIF/2CIF/CIF/QCIF
Video output
2-ch, BNC (1.0Vp-p, 75Ω)
Frame rate
PAL:25fps; NTSC:30fps
Bit rate
32Kbps-2048Kbps, or user defined,
Max 6144Kbps
Audio output
2-ch, BNC (linear, 600Ω)
Audio Bit
rate
16kbps
Synchronous
Playback
4-ch
Hard disk
Interface
type
8, SATA interface
Capacity
Each supports more than 2TB capacity
External
interface
Network
interface
1, RJ45 10M/100M/1000M adaptive Ethernet
Serial
interface
1 RS-232 interface (for parameters
configuration, maintenance, transparent
channel);
1 RS-485 interface (for PTZ control);
1 RS-485keyboard interface (for special
keyboard control)
USB
interface
3, USB2.0

HIKVISION DS-9104HFI-S Specifications

General

Brand	HIKVISION
Model	DS-9104HFI-S
Category	DVR
Language	English
