DS-K2600 Serial Access Controller
26
Chapter 5
Settings
5.1 Initializing the Hardware
Steps:
1. The jumper cap jumps from Normal to Initial.
2. Disconnect the power and restart the access controller, the controller buzzer
buzzes a long warning.
3. After the buzzer stops, jump the jumper cap back to Normal.
4. Disconnect the power and restart the access controller.
Figure 5-1 Initialization Dial-up
Note:
The initializing of the hardware will restore all the parameters to the default
setting and all the device events are wiping out.
5.2 Relay Input NO/NC
Lock Relay Output
Lock Relay Normally Open Status

HIKVISION DS-K2604 Specifications

General

Product type	Access controller
Certification	CE, FCC
Product color	Gray
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C

Weight and Dimensions

Depth	370 mm
Width	345 mm
Height	90 mm
