whether the image is gotten from the optimum angle. If not,
adjust the viewing angle.
Figure 2-6 Adjust Viewing angle
1). Hold the camera body and rotate the enclosure to adjust the
pan angle [0° to 360°].
2). Move the camera body up and down to adjust the tilt angle [0°
to 75°].
3). Rotate the camera body to adjust the rotation angle [0° to
360°].
Mounting with Junction Box
Before you start:
● You need to purchase a junction box separately if you adopt the
mounting with a junction box.
● Both wall mounting and ceiling mounting are suitable for the
turret camera. Wall mounting will be taken as an example in
this section. And you can take steps of wall mounting as a
reference for the ceiling mounting.
To Next Page
