HIKVISION TURBO HD Full Time Color Series User Manual

3 Menu Description
Purpose:
Call the menu by clicking button on the PTZ Control
interface, or call the preset No.95.
Steps:
1. Connect the camera with the TVI DVR, and the
monitor, shown as the figure 3-1.
Camera
TVI DVR
Monitor
Figure 3-1 Connection
2. Power on the analog camera, TVI DVR, and the
monitor to view the image on the monitor.
3. Click PTZ Control to enter the PTZ Control interface.
4. Call the camera menu by clicking button, or call
the preset No. 95.
EXPOSURE
MAIN MENU
VIDEO
SETTINGS
FUNCTIONS
FACTORY
DEFAULT
EXIT
EXPOSURE MODE
AGC
SLOW SHUTTER
CONTRAST
SHARPNESS
SATURATION
3 DNR
MIRROR
BACK
BACK
SAVE & EXIT
BACK
FORMAT
EXIT
SAVE & EXIT
BRIGHTNESS
WHITE BALANCE
SMART
LIGHT
BACK
EXIT
SAVE & EXIT
MODE
PRIVACY
MOTION
DPC
EXIT
SAVE & EXIT
EXIT
SAVE & EXIT
Figure 3-2 Main Menu Overview
5. Click the direction arrow to control the camera.
1). Click up/down direction button to select the
item.
2). Click Iris + to confirm the selection.
3). Click left/right direction button to adjust the
value of the selected item.
