Hilti C7 User Manual

10
en
3. Accessories
CA 7/36 adaptor for BP 12, BP 40, BP 72 and RB 10
Voltage Designation Battery type Charging time Charging time Examples of tools
with C7/24 with C7/36-ACS using this battery
9.6 V SFB 105 NiMH 45 min. 30 min. SF 100-A, SB 10, HIT-BD 2000
9.6 V SBP 10 NiCd 30 min. 20 min. SF 100-A, SB 10, HIT-BD 2000
9.6 V RB 10 NiCd 20 min. 15 min. FS 10 Ferroscan (with adaptor)
12 V SFB 125 NiMH 45 min. 30 min. SF 120-A, SB 12
12 V SBP 12 NiCd 30 min. 20 min. SF 120-A, SB 12
12 V SFB 121 NiCd 30 min. 20 min. SF 121-A
12 V SFB 126 NiMH 45 min. 30 min. SF 121-A
12 V BP 12 NiCd 20 min. 15 min. TCI 12 (with adaptor)
15.6 V SFB 150 NiCd 30 min. 20 min. SF 150-A
15.6 V SFB 155 NiMH 45 min. 45 min. SF 150-A
18 V SFB 180 NiCd 34 min. 20 min. SF 4000-A, SF 180-A
18 V SFB 185 NiMH 51 min. 45 min. SF 4000-A, SF 180-A
24 V B24/2.0 NiCd 48 min. 20 min. UH 240-A, TE 2-A, WSR 650-A
24 V B24/2.4 NiCd 48 min. 24 min. UH 240-A, TE 2-A, WSR 650 A
24 V B24/3.0 NiMH 72 min. 30 min. UH 240-A, TE 2-A, WSR 650-A
24 V BP 40,
BP 72 NiCd 41–72 min. 20–36 min. TE 5-A (with adaptor)
36 V BP 6-86 NiCd 34 min. TE 6-A (only C 7/36-ACS!)
2. Description
The charger is designed for charging Hilti batteries with
a nominal voltage of 7.2 – 36 volts (C 7/36-ACS charg-
er) or 7.2 – 24 volts (C 7/24 charger).
Items supplied
– C 7/24 standard charger
or
– C 7/36-ACS top charger
– Operating instructions
4. Technical data
Charger C 7/24 C 7/36-ACS
Refresh function Manual refresh function Automatic refresh function
(“Refresh” button)* (“Refresh” function)*
Cooling By convection Active cooling system
Mains voltage 100–127 V and 220–240 V 100–127 V and 220–240 V
Mains frequency 50/60 Hz 50/60 Hz
Battery types NiCd, NiMH NiCd, NiMH
Output voltage 7.2 – 24 V 7.2 – 36 V
Output power 90 W 200 W
Charging times See table in section 2.
Weight Approx. 1.0 kg approx. 1.0 kg
Supply cord length Approx. 2 m approx. 2 m
Dimensions (L×B×H) 170×165×88 mm 170×165×88 mm
Charging control Electronic charging control (microcontroller)
Protection class Electrical protection class II (double insulated) Z
Right of technical changes reserved * See section 7.3 for further information.
