Hisense 43A7100F User Manual

15
Specifications
Features, appearance and specifications are subject to change without notice.
Item
43" 50"
Dimension
(W × H × D)
Without Stand
37.8 × 22.0 × 3.3 inches
(961 × 560 × 83 mm)
43.9 × 25.5 × 3.2 inches
(1116 × 648 × 82 mm)
With Stand
37.8 × 24.1 × 7.7 inches
(961 × 613 × 196 mm)
43.9 × 27.9 × 8.9 inches
(1116 × 709 × 226 mm)
Weight
Without Stand
15.0 lbs (6.8 kg) 21.6 lbs (9.8 kg)
With Stand
15.2 lbs (6.9 kg) 21.8 lbs (9.9 kg)
Active Screen Size (Diagonal)
108 cm 126 cm
Screen resolution
3840 × 2160 3840 × 2160
Audio power
7W + 7W 8W + 8W
Operating mode power density
0.015 Watts/cm² 0.020 Watts/cm²
Power consumption when turned off
< 0.5 W < 0.5 W
Power consumption in standby mode
0.5 W 0.5 W
Power consumption
Please refer to the rating label.
Power supply
Please refer to the rating label.
Receiving
systems
Analog
PAL-D/K, B/G, I, SECAM-D/K, B/G
Digital
DVB-T/T2, DVB-C, DVB-S/S2
Wireless
LAN Module
specifications
Model
ZDGF7638GU-C WTA1M2500
Frequency
Range
2.4~2.4835GHz 2.4~2.4835GHz
Output Power
(Max.)
2.4~2.4835GHz 17dBm 2.4~2.4835GHz 17dBm
Bluetooth
Module
specifications
Model
ZDGF7638GU-C WTA1M2500
Frequency
Range
2.4~2.4835GHz 2.4~2.4835GHz
Output Power
(Max.)
2.4~2.4835GHz, Class1,
6dBm
2.4~2.4835GHz, Class1,
6dBm
Environmental conditions
Temperature: 5°C - 45°C
Humidity: 20% - 80% RH
Atmospheric pressure: 86 kPa - 106 kPa
HDMI Input
RGB / 60 Hz (640×480, 800×600, 1024×768)
YUV / 60 Hz (480 I, 480 P, 720 P, 1080 I, 1080 P)
YUV / 50Hz (576 I, 576 P, 720 P, 1080 I, 1080 P)
3840×2160 / 24Hz, 3840×2160 / 25Hz
3840×2160 / 30Hz, 3840×2160 / 50Hz,
3840×2160 / 60Hz
