5
TV Rear
TV Rear
Power Input
NOTES
Check the jacks for position and type before making any connections. Loose
connections can result in image or color problems. Make sure that all connections
are tight and secure.
The TV may not be compatible with all external devices. To check compatibility,
please refer to the user manual of external device.
Do not connect external equipment while TV's power cord is plugged in. It may
cause electric shock.
Service jack is not available for you to connect an external device. It can only be
used by our factory for testing
purposes.
HEADPHONE
SERVICE
ANT
HDMI 3(
4K@60Hz
)
HDMI 1(
4K@60Hz
)
DC 5V
0.5A(MAX)
USB 2
DIGITAL
AUDIO OUT
DC 5V 0.5A(MAX)
USB 1
HDMI 2(
4K@60Hz
)
ARC
LAN
AV IN
HDMI 4(
4K@60Hz
)
VIDEOLR
