Serial Protocol
NOTE
•
Verify is the exclusive OR of Length, Command code, ID and Data.
•
All data are hexadecimal values.
•
For all commands received by the device, the protocol header needs to be changed to AB AB and the
protocol tail needs to be changed to CD CD when returning to the PC.
•
Precautions for control terminal programming: For the power-on command, AB AB 01 04 A1 00 00 00
CD CD are returned after the power-on action is executed; if the command is not received, the power-on
command needs to be sent again. After the TV is turned on, the PC will receive AB AB 01 04 A1 00 00 00
CD CD again, and then the PC can send a control command to the device. If the correct command is not
returned after any command is sent, the command should be sent again at least after 500ms.
•
In standby state, the device only supports startup commands.
Protocol
header
ID Length Command code Protocol tail
Switch on/
o󰀨
Ｏｎ
ＰＣ ｔｏ
ｄｅｖｉｃｅ
ＤＤ ＦＦ ０１ ０４ Ａ１ ００ ００ ００ ＢＢ ＣＣ
Ｏｎ
Ｄｅｖｉｃｅ ｔｏ
ＰＣ
ＡＢ ＡＢ ０１ ０４ Ａ１ ００ ００ ００ ＣＤ ＣＤ
Ｏｆｆ
ＰＣ ｔｏ
ｄｅｖｉｃｅ
ＤＤ ＦＦ ０１ ０４ Ａ１ ０１ ００ ００ ＢＢ ＣＣ
Ｏｆｆ
Ｄｅｖｉｃｅ ｔｏ
ＰＣ
ＡＢ ＡＢ ０１ ０４ Ａ１ ０１ ００ ００ ＣＤ ＣＤ
Volume
Control
ＰＣ ｔｏ
ｄｅｖｉｃｅ
ＤＤ ＦＦ ０１ ０４ Ａ１ ０７ ００ ＸＸ ＢＢ ＣＣ
Ｄｅｖｉｃｅ ｔｏ
ＰＣ
ＡＢ ＡＢ ０１ ０４ Ａ１ ０７ ００ ＸＸ ＣＤ ＣＤ
Ｒｅｍａｒｋ ＸＸ ｉｓ ｔｈｅ ｖｏｌｕｍｅ ｖａｌｕｅ．
Bright-
ness
Control
ＰＣ ｔｏ
ｄｅｖｉｃｅ
ＤＤ ＦＦ ０１ ０４ Ａ１ ０８ ００ ＸＸ ＢＢ ＣＣ
Ｄｅｖｉｃｅ ｔｏ
ＰＣ
ＡＢ ＡＢ ０１ ０４ Ａ１ ０８ ００ ＸＸ ＣＤ ＣＤ
Ｒｅｍａｒｋ ＸＸ ｉｓ ｔｈｅ ｂｒｉｇｈｔｎｅｓｓ ｖａｌｕｅ．
