Hisense 75A7100FTUK User Manual

13
Specifications
Features, appearance and specifications are subject to change without notice.
Item
58"
Dimension
(W × H × D)
Without Stand
50.9 × 29.6 × 3.3 inches
(1293 × 753 × 84 mm)
With Stand
50.9 × 32.0 × 8.9 inches
(1293 × 813 × 226 mm)
Weight
Without Stand 30.0 lbs (13.6 kg)
With Stand 30.4 lbs (13.8 kg)
Active Screen Size (Diagonal) 146 cm
Screen resolution 3840 × 2160
Audio power 8 W + 8 W
Operating mode power density 0.014 Watts/cm²
Power consumption when turned off
< 0.5 W
Power consumption in standby mode
0.5 W
Power consumption Please refer to the rating label.
Power supply Please refer to the rating label.
Receiving
systems
Analog PAL-D/K, B/G, I, SECAM-D/K, B/G
Digital DVB-T/T2, DVB-C, DVB-S/S2
Wireless
LAN Module
specifications
Model WTA1M2500
Frequency
Range
2.4~2.4835GHz
Output Power
(Max.)
2.4~2.4835GHz 17dBm
Bluetooth
Module
specifications
Model WTA1M2500
Frequency
Range
2.4~2.4835GHz
Output Power
(Max.)
2.4~2.4835GHz, Class1, 6dBm
Environmental conditions
Temperature: 41°F - 95°F (5°C - 35°C)
Humidity: 20% - 80% RH
Atmospheric pressure: 86 kPa - 106 kPa
HDMI Input
RGB / 60 Hz (640×480, 800×600, 1024×768)
YUV / 60 Hz (480 I, 480 P, 720 P, 1080 I, 1080 P)
YUV / 50Hz (576 I, 576 P, 720 P, 1080 I, 1080 P)
3840×2160 / 24Hz, 3840×2160 / 25Hz
3840×2160 / 30Hz, 3840×2160 / 50Hz,
3840×2160 / 60Hz

Hisense 75A7100FTUK Specifications

General

Color depth	8 bit
Comb filter	3D
Screen shape	Flat
Response time	20 ms
Display diagonal	75 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	-
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Display diagonal (metric)	189 cm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	250 W
Power consumption (standby)	0.5 W
Power consumption (typical)	200 W
Internet TV	No
Operating system version	U4.0
Operating system installed	VIDAA
Package depth	201 mm
Package width	1865 mm
Package height	1150 mm
Package weight	36000 g
Audio decoders	DTS
RMS rated power	10 W
Number of speakers	2
Product color	Black
Panel mounting interface	400 x 300 mm
Tuner type	Analog & digital
Analog signal format system	PAL BG, PAL DK, PAL I, SECAM B/G, SECAM D/K
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Processor cores	4
Audio formats supported	FLAC, MP2, MP3, MP4, WMA, WMV
Image formats supported	BMP, GIF, JPEG, MPO, PNG
Video formats supported	3GP, AVI, FLV, MKV, MOV, MP4, MPEG, MPG, OGM, VOB, WEBM, WMV
Video compression formats	H.264, H.265, HEVC, MPEG2, MPEG4, MVC, VC-1, VP9
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Number of OSD languages	35
On Screen Display (OSD) languages	ALB, ARA, BEL, BOS, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth (with stand)	356 mm
Width (with stand)	1676 mm
Height (with stand)	1040 mm
Weight (with stand)	25600 g
Depth (without stand)	79 mm
Height (without stand)	965 mm
Weight (without stand)	25100 g
