Hitachi 32HDT50 User Manual

32HDT20 32" PLASMA TV
PART NUMBER PART DESCRIPTION
FPF17R-ABL5004 ADDRESS BUS BOARD (LEFT)
FPF17R-ABR5005 ADDRESS BUS BOARD (RIGHT)
FPF17R-LGC5009 LOGIC BOARD
FPF17R-XSS5010 X-SUS BOARD
FPF17R-YSS5011 Y-SUS BOARD
HA01023 POWER UNIT
JP04843 SIGNAL/AUDIO PWB ASSEBLY(SVC)
JT22733 AC FILTER/POWER PWB ASSEMBLY
JT23201 POW/FIL ASSY 32HDT20
42HDT20 42" PLASMA TV
PART NUMBER PART DESCRIPTION
FPF16R-ABL5004 ADDRESS BUS BOARD (LEFT)
FPF16R-ABR5005 ADDRESS BUS BOARD (RIGHT)
FPF16R-LGC5006 LOGIC BOARD
FPF16R-XSS5002 X-SUS BOARD
FPF16R-YSS5003 Y-SUS BOARD
HA00994 POWER UNIT
JP05406 SIGNAL/AUDIO PWB ASSEMBLY
JT23006
A
C FILTER PWB ASSEMBLY
42HDT20A 42" PLASMA TV
PART NUMBER PART DESCRIPTION
FPF16R-ABL5010 ADDRESS BUS BOARD (LEFT)
FPF16R-ABR5011 ADDRESS BUS BOARD (RIGHT)
FPF16R-LGC5007 LOGIC BOARD
FPF16R-XSS5008 X-SUS BOARD
FPF16R-YSS5009 Y-SUS BOARD
HA00994 POWER UNIT
JP05406 SIGNAL/AUDIO PWB ASSEMBLY
JT23006
A
C FILTER PWB ASSEMBLY
32HDT50 32" PLASMA TV
PART NUMBER PART DESCRIPTION
FPF17R-ABL5014 ADDRESS BUS BOARD(LEFT)32HDT50
FPF17R-ABR5015 ADDRESS BUS BOARD(RIGHT)32HDT5
FPF17R-LGC5018 LOGIC BOARD 32HDT50
FPF17R-XSS5016 X-SUS BOARD 32HDT50
FPF17R-YSS5017 Y-SUS BOARD 32HDT50
HA01121
K
POWER UNIT MPF7103-K
42HDT50 42" PLASMA TV
PART NUMBER PART DESCRIPTION
FPF16R-ABL5010 ADDRESS BUS BOARD (LEFT)
FPF16R-ABR5011 ADDRESS BUS BOARD (RIGHT)
FPF16R-LGC5007 LOGIC BOARD
FPF16R-XSS5008 X-SUS BOARD
FPF16R-YSS5009 Y-SUS BOARD
FPF16RLGC500703 LOGIC PWB (PANEL ENDING UB-75)
HA01133
K
POWER UNIT MPF7404L-K
