12
English
SPECIFICATIONS
Item Model C 10FSHC
Motor Type Series commutator motor
Power source Single-phase AC 60Hz
Voltage (Volts) 120
Full-load current (Amp) 15
Laser Marker Maximum output
<5mW CLASS
a Laser Product
Wave length 630 – 660 nm
Laser medium Laser Diode
Applicable saw
blade
Outside Dia. 10" (255 mm)
Hole Dia. 5/8" (15.9 mm)
No load speed 3,200/min
Max.
sawing
dimension
Head Turntable Max. sawing dimension
Miter 0 0 (With anchor plate)
Max. Height
Max. Width
(Without anchor plate)
Max. Height
Max. Width
3-1/2" (89 mm)
11-1/2" (292 mm)
2-1/2" (64 mm)
12-1/2" (318 mm)
0 Left 45°
or
Right 45°
(With anchor plate)
Max. Height
Max. Width
(Without anchor plate)
Max. Height
Max. Width
3-1/2" (89 mm)
8" (204 mm)
2-1/2" (64 mm)
8-3/4" (222 mm)
0 Left 55° (With anchor plate)
Max.Height
Max.Width
(Without anchor plate)
Max.Height
Max.Width
3-1/2" (89 mm)
6-7/8" (176 mm)
2-1/2" (64 mm)
7-1/4" (182 mm)
0 Right 60° (With anchor plate)
Max.Height
Max.Width
(Without anchor plate)
Max.Height
Max.Width
3-1/2" (89 mm)
5-3/4" (146 mm)
2-1/2" (64 mm)
6-1/4" (158 mm)
Bevel Left 4 0 (With anchor plate)
Max. Height
Max. Width
(Without anchor plate)
Max. Height
Max. Width
1-3/4" (45 mm)
11-1/2" (292 mm)
1-5/8" (41 mm)
12-1/2" (318 mm)
Right 45° 0 (With anchor plate)
Max. Height
Max. Width
(Without anchor plate)
Max. Height
Max. Width
1" (25 mm)
11-1/2" (292 mm)
3/4" (19 mm)
12-1/2" (318 mm)
Compound Left 45° Left 45°
or
Right 45°
(With anchor plate)
Max. Height
Max. Width
(Without anchor plate)
Max. Height
Max. Width
1-3/4" (45 mm)
8" (204 mm)
1-
5/8" (41 mm)
8-3/4" (222 mm)
Right 45° Left 45°
or
Right 45°
(With anchor plate)
Max. Height
Max. Width
(Without anchor plate)
Max. Height
Max. Width
1" (25 mm)
8" (204 mm)
3/4" (19 mm)
8-3/4" (222 mm)
Miter sawing range Left 0° – 55° Right 0° – 6
Bevel sawing range Left 0° – 48° Right 0° – 48°
Compound sawing range Left (Bevel) 0° – 45°, Left (Miter) 0° – 4
Right (Bevel) 0° – 45°, Right (Miter) 0° – 4
Net weight 45.6 lbs. (20.7 kg)
Cord 2 Conductor type cable 6ft. (1.8 m)
000BookC10FSHCNA.indb12000BookC10FSHCNA.indb12 2017/06/2018:36:292017/06/2018:36:29
