-2-
1. Specifications
Model
Item
CS 33EDT CS 33EDTP Remarks
Engine type Air-cooled, two-cycle gasoline engine
Cylinder quantity
- inner diameter x stroke
1-37 x 30 mm
Engine displacement 32.2 mL
Momentary no-load
revolutions
11,500 to 13,000 min
-1
Service revolutions 8,000 to 10,000 min
-1
Revolutions at actual work
Idling revolutions 2,800 to 3,200 min
-1
Rotation direction Clockwise
When viewed from end of
the output shaft
Service fuel
Mixed gasoline
Gasoline: dedicated two-cycle oil = (25 to 50): 1
Fuel tank capacity 290 mL (run continuously for 19 to 24 minutes)
Carburetor Diaphragm type (with primer pump) From Walbro
Spark plug NGK BPMR7A
Startup method Recoil starter method
Air cleaning method Dry
Stopping method Ground
Muffler type Silencer
Power transmission
method
Automatic centrifugal clutch
Guide bar length 350 mm (14 inch), SN, 300 mm (12 inch), SN SN: Sprocket nose
Saw chain used 91VG-52, 91VG-45 From Oregon
Saw chain Pitch: 9.53 mm (3/8”), Gauge: 1.27 mm (0.05”)
Sprocket Star, six teeth
Chain oil feeding method Automatic feed
Without adjusting amount
of oil
Chain oil tank capacity 180 mL
Chain oil discharge rate 8 mL/min. (9,000 min
-1
)
Chain oil used Dedicated chain oil
Handle Equipped with anti-vibration device
Anti-vibration mechanism Engine floating type
Dry weight 3.4 kg
Excluding saw chain and
guide bar
Overall dimensions
(L x W x H)
277 x 255 x 220 mm
Sound pressure level LpA 100 dB(A)
Vibration level
(Front/Rear)
4.4 / 6.1 m/s
2
Exhaust gas emissions
(Stage 2)
Noncompliant Compliant
Standard accessories
• Combi box wrench 13 x 19 ---------------------- 1
• Chain case -------------------------------------------
1
• Spike set ---------------------------------------------- 1
Europe, Australia, China and Russia only.
Mounted on the body for Europe and Australia.
• Guide bar --------------------------------------------- 1
• Saw chain -------------------------------------------- 1
SPECIFICATIONS
To Next Page
