OPERATION AND MAINTENANCE
NOTE:
The information contained in this Instruction Manual is designed to assist you in the safe operation and maintenance of the
compressor.
Some illustrations in Instruction Manual may show details or attachments that differ from those on your own compressor.
NAME OF PARTS
Fig. 1
SPECIFICATIONS
Model EC 510
Motor
Single-phase, universal Motor
Power Source
Single-phase, 120V AC 60 Hz
Running Horse Power
1.1 HP (0.8 kW)
Current
8 A
Tank Capacity 6 gal. (22.7 ltr)
Maximum Pressure 145 PSI (10 bar)
Free Air Delivery
at 40 PSI
(2.8 bar)
2.8 CFM
(80 ltr/min)
at 90 PSI
(6.2 bar)
2 CFM
(56,6 ltr/min)
Lubrication Oil-less
Rubber
bumper
(Foot)
Drain cock (discharge tap)
Knob of the
pressure switch
Handle
Motor
cooling fan
Tank
Pressure gauge
(A) indicates the
pressure in the air
tank
Pressure gauge
(B) indicates the
working pressure
Quick air coupler
(air outlet)
Knob of the
pressure
reducer
Safety valve
